The pressure operator

The pressure operator from physics from the ``equation of state'' that the time rate of change of the pressure is an external source s(x,y,t) minus the divergence of the velocity times the incompressibility K.
{\partial p \over \partial t} \quad =\quad
\ -\
K ...
 ...ial u \over \partial x} +
{\partial v \over \partial y}
\right)\end{displaymath} (11)

In the heat flow equation the field variable is a scalar (the temperature). For wave propagation in two dimensions, the wavefield variable has three components, pressure and two components of material velocity. The pressure operator P transforms ptx,y to pt+1x,y but it is an identity matrix for the two components of velocity (which will actually be transformed in a later process). We distribute the wavefield variables throughout space with this tiling:
 p&u& p&u& p&u& p&u&...
 ...& v& & v& & v& & \\  \\  \downarrow &&&&&&&& \\  y
 \end{array}\end{displaymath} (12)
We define the basic tile for this discrete mesh as
{\vert c\vert c\vert}
 p & u \\  \hline
 v & \\  \hline
 \end{array}\end{displaymath} (13)
Computationally we refer to this basic tile on the inputs as $\vec q(x,y)$and on the outputs as $\vec r(x,y)$although the three components in the tile are at slightly different physical locations from one another. Expressing the pressure equation for these tiles we have
p_{t+1}^x \quad =\quad s_t^x + p_t^x
 - \;
 {K \Delta t \ove...
 ]\end{displaymath} (14)
In subroutine pressure() below the input pressure and velocity field is q(x,y,*) and the output is r(x,y,*). Equation (14) is expressed in the subroutine on the line beginning with r(x,y,p)=.

# operator of pressure change from divergence of velocity
subroutine pressure( adj, add, kappa,       q,nx,ny,    r )
integer              adj, add,                nx,ny,       x, y,    p,   u,   v
real                           kappa(nx,ny),q(nx,ny,3), r(nx,ny,3)
call        adjnull( adj, add,              q,nx*ny*3,  r,nx*ny*3)
							          p=1; u=2; v=3
do x= 2, nx-1 {
do y= 2, ny-1 {
    if( adj == 0) {
	r(x,y,p)= r(x,y,p) + q(x,y,p) - (q(x,y,u) - q(x-1,y  ,u)) * kappa(x,y) -
					(q(x,y,v) - q(x  ,y-1,v)) * kappa(x,y)
	r(x,y,u)= r(x,y,u) + q(x,y,u)
	r(x,y,v)= r(x,y,v) + q(x,y,v)
    } else {
	q(x  ,y  ,p)= q(x  ,y  ,p) + r(x,y,p)
	q(x  ,y  ,u)= q(x  ,y  ,u) - r(x,y,p) * kappa(x,y)  + r(x,y,u)
	q(x-1,y  ,u)= q(x-1,y  ,u) + r(x,y,p) * kappa(x,y)
	q(x  ,y  ,v)= q(x  ,y  ,v) - r(x,y,p) * kappa(x,y)  + r(x,y,v)
	q(x  ,y-1,v)= q(x  ,y-1,v) + r(x,y,p) * kappa(x,y)
return; end

Notice that the identity matrix ``pass through'' of the velocity components shows up as two extra assignments in the forward operator and thus as two added terms in the adjoint operator.

Figure 1
