Objective function and solution

We can apply the approximation in equation (10) to the objective functions. For example, from equations (3) and (7) we can derive
 \begin{displaymath}
\begin{array}
{lll}
E^0(t,x,\Delta p) & = & \displaystyle{\s...
 ...rtial t}j\Delta p \Delta x \right)\right]^2
\right\}\end{array}\end{displaymath} (11)
The optimal estimate of $\Delta p$ is the minimizer of this function. Because the objective function is a quadratic function of the unknown $\Delta p$, one can use the standard least-squares techniques to find the solution of this linear optimization problem:
\begin{displaymath}
\Delta p = \displaystyle{\displaystyle{\sum^{L_t}_{i=-L_t}}W...
 ...ystyle{\partial P \over \partial t}j\Delta x \right)^2 \right]}\end{displaymath} (12)
Once $\Delta p$ is found for each t, the pick can be improved by using equation (9).
